Cat5e Patch Panel, 2U 48 Port, Rack Mount
Features
UL and cUL Listed
48 ports
Cat5e rated
T568A/T568B compliant
110, Krone or Dual IDC terminations
Details about Cat5e Patch Panel, 2U 48 Port, Rack Mount
Cat5e Patch Panel, 2U 48 Port, Rack Mount
Part No.: P5U48
Product Overview
A patch panel is a device which contains a number of RJ45 ports. Patch panels are used for connecting incoming and outgoing wires of a local area network (LAN) or a telecommunication system. In a LAN, the patch panel connects network computers to each other and switches or hubs with patch cables. Patch panels also give the benefit of organization for a clean network deployment.
Our UL Listed Cat5e patch panel exceeds TIA and ISO component specifications, supporting network convergence protocols delivering maximum bandwidth and extended reliability for all LAN, multimedia, and Power over Ethernet applications. To the front of the panel each port is numbered and has a designated label area for clear port identification.
Applications
For installation in 19” racks/cabinets
Suitable for applications that use 22-26 AWG network cables
1000BASE-T Gigabit Ethernet, 100BASE-TX Fast Ethernet, 10BASE-T Ethernet applications
Voice, video and other applications
